Low-profile, light duty collector with a versatile filtration system which allows for disposable bag, HEPA cartridge and gas phase filter.
Low-profile, light duty dust collector and fume extractor with a versatile filtration system that allows for disposable bag, HEPA cartridge and gas phase filter. Custom chemical filters can be incorporated to deal with specific gas phase contaminants. Whisper quiet operation.
| Product Number | Pressure | CFM | Volts/Phase/Hz | Amps | Shipping Weight | Width | Height | Depth | Noise (dB) | Max Debris Capacity (in3) | Filter Sequence | Filter Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1-0030-0711 (iSeries with 1.5″ inlet) |
90″ WC | 141 | 120/1/60 | 8 | 37 lbs (17 kg) |
9″ | 19″ | 9″ | 56dB(A) | 350 | • 8” Dust/Odor/HEPA Filter Pack AG365-GPC | • MERV 8 (Dust) • N/A (Odor) • MERV 17 (HEPA) |
| 1-0030-0701 (Analog with 1.5″ inlet) |
90″ WC | 141 | 120/1/60 | 8 | 37 lbs (17 kg) |
9″ | 19″ | 9″ | 56dB(A) | 350 | • 8” Dust/Odor/HEPA Filter Pack AG365-GPC | • MERV 8 (Dust) • N/A (Odor) • MERV 17 (HEPA) |
| 1-0030-0712 (iSeries with 3″ inlet) |
90″ WC | 141 | 120/1/60 | 8 | 37 lbs (17 kg) |
9″ | 19″ | 9″ | 56dB(A) | 350 | • 8” Dust/Odor/HEPA Filter Pack AG365-GPC | • MERV 8 (Dust) • N/A (Odor) • MERV 17 (HEPA) |
| 1-0030-0702 (Analog with 3″ inlet) |
90″ WC | 141 | 120/1/60 | 8 | 37 lbs (17 kg) |
9″ | 19″ | 9″ | 56dB(A) | 350 | • 8” Dust/Odor/HEPA Filter Pack AG365-GPC | • MERV 8 (Dust) • N/A (Odor) • MERV 17 (HEPA) |
| 1-0030-0703 (Analog with 1.5″ inlet) |
90″ WC | 141 | 120/1/60 | 8 | 37 lbs (17 kg) |
9″ | 19″ | 9″ | 56dB(A) | 350 | • Yellow Bag AG320-02 • 1” Charcoal Odor Filter F229 • 1” HEPA Filter F230 |
• MERV 13 • N/A • MERV 17 |
| 1-0030-0722 (iSeries with 3″ inlet) |
90″ WC | 141 | 120/1/60 | 8 | 37 lbs (17 kg) |
9″ | 19″ | 9″ | 56dB(A) | 350 | • White Bag AG321-03 • 1” Charcoal Odor Filter F229 • 1” HEPA Filter F230 |
• MERV 13 • N/A • MERV 17 |
| 1-0030-0704 (Analog with 3″ inlet) |
90″ WC | 141 | 120/1/60 | 8 | 37 lbs (17 kg) |
9″ | 19″ | 9″ | 56dB(A) | 350 | • White Bag AG321-03 • 1” Charcoal Odor Filter F229 • 1” HEPA Filter F230 |
• MERV 13 • N/A • MERV 17 |
Learn how to get the most out of your Quatro Air unit and troubleshoot common problems. You can also download the owner’s manual for this unit for technical details and instructions.
